- High throughput: 75-120 cm3 per hour
- Proven gold recovery rates exceeding 97%
- Trommel easily movable on-site
- Built with longevity in mind
- Works well in remote locations
- Requires minimum personel to operate
- Low operating and maintenance costs
See the Minequip Gold Rotary Trommel in action
Gold Rotary Trommel Wash Plants Shipped Worldwide – Gold Mining Equipment.
Minequip’s gold mining equipment rotary trommel wash plants are manufactured for commercial use in small to medium sized gold recovery operations, and our gold mining equipment is used successfully in production gold mines in New Zealand, Mongolia, Papua New Guinea, Bolivia, Ghana and Cameroon.
Based in New Zealand’s South Island, Minequip knows mining – after all, the gold rushes started here back in 1865. Those first pioneers have passed down their knowledge of gold mining equipment through the generations and our design engineers have over 60 years combined experience in the gold mining equipment engineering industry.
Minequip designs and manufactures mobile gold rotary trommel wash plants that are economical and easy to operate.
Gold Recovery Rates Exceeding 97%
Our Mobile 1200 gold rotary trommel wash plant gold mining equipment is unique to the gold mining industry and is easy to move on-site with proven gold recovery rates exceeding 97%.
We pride ourselves on producing innovative gold rotary trommel technology which can improve your gold recovery rate and maximize productivity.
Gold Trommel Engineering Design
Built Tough For Reliability & Longevity
- Built using NZ Mill Grade Steel and assembled by skilled welders who are AS/NZS ISO9606 certified.
- Very few moving parts 4x Trunnion Rollers 1x Thrust Bearing 1x Chain Tensioner. (there is no need to stock a large spare parts inventory)
- Hopper has a water jacket 270◦around the perimeter of the hopper which wets the material with water jets before entering the trommel.
- Hopper has replaceable 10mm steel hopper skins.
- Trommel has replaceable 10mm wear bars which to give the trommel longevity.
- Adjustable sparge pipe where you can direct the water flow directly to the wash in the trommel.
- Catch Tray is lined with 6mm hard latex rubber to give the plant years of service before the catch tray rubber must be replaced.
- Catch Tray has steel baffles to eliminate water surges
- Catch tray has two water direction paddles where you can equally distribute water flow to the sluice tables.
- Sluice tables have a water added boil box for nugget collection before the wash goes over the sluice tables where standard Californian riffles are used over 3m matting. (Hinged Stainless-Steel Hydraulic Riffles are optional)
Minequip New Zealand manufactures commercial scale gold mining equipment rotary trommel wash plants directly for sale. Our gold mining equipment is built to withstand the demands of small to medium production gold mining operations.
We know the high demands placed on commercial gold rotary trommel wash plant equipment, and build our gold mining equipment to withstand the harsh conditions of a production gold mine, with efficiency and durablility the key ingredients in every manufactured processing plant.
